Boards & white-label devices
Boards
#HiFi #Streamers
Accelerate your product development with Volumio’s OEM hardware solutions.
Brands and manufacturers can integrate our ready-made boards, or customized evolutions of them, directly into their own enclosures and brand identity.
Whether derived from our proven devices or built around the Streamplay module, each solution is engineered for performance, reliability, and seamless integration.
Powered by Volumio OS, these boards give you a solid, future-ready foundation while leaving full freedom to design the look, feel, and personality of your product.
White-label devices
#HiFi #Streamers
Bring your brand to market faster with Volumio’s white-label OEM offering.
Our full lineup of award-winning audio devices, widely praised by reviewers and trusted by audiophiles worldwide, is available ready to ship under your own brand.
You keep the identity, we deliver the proven technology, performance, and reliability powered by Volumio OS.
Explore our product portfolio, review detailed specifications, and contact us to learn more about commercial conditions and how quickly your branded range can become a reality.
Hardware & I\Os
CPU RK3308B, Quad-core ARM Cortex-A35 CPU 1.3GHz
RAM 512MB DDR3
EMMC 8GB onboard storage
Support for additional SD-card external storage
Ethernet 10/100M
WiFi 2.4GHz 802.11 b/g/n with highly optimized performance
Bluetooth 4.2
External Antenna connector on WiFi/BT module
Digital audio input and output via I2S interface, playback up to 192KHz/24bit
Digital audio output via S/PDIF interface, playback up to 192KHz/24bit (on A0 variant)
GPIO, UART, I2C and USB2.0 interfaces
Two versions are available:
– A31, pin-to-pin compatible with Linkplay A31
– A0 with its own pin distribution and a digital output (not available in the A31 streamplay module).
Software
Volumio Premium OS full license + mobile app
and its Over The Air updates during one year.
The kit includes APIs access & support.
Evaluation & development platform for Streamplay A0 and A31 modules
Sockets for Streamplay modules, A0 & A31 variants
Barrel-jack connector for 5.1 V DC input
DAC PCM5100A, up to 192kHz/24bit, 2Vrms
Stereo unbalanced analog output on RCA connectors
Headphone amplifier PAM8908
Stereo headphone output on 3.5mm jack connector
Digital S/PDIF Coaxial output on RCA connector, up to 192kHz/24bit
Digital S/PDIF Coaxial output on TOSLINK connector, up to 192kHz/24bit
10/100M Ethernet interface
SD-card interface for external storage
2 x USB 2.0 port on Type-A connector
2 x USB 2.0 port exposed on 2.54mm pitch pin-header
1 x USB 2.0 OTG port on Type-C connector
I2S interface exposed on 2.54mm pitch pin-header
I2C interface exposed on 2.54mm pitch pin-header
UART interface exposed on 2.54mm pitch pin-header
6 x GPIO exposed on 2.54mm pitch pin-header
1 x push-button (factory-reset or custom functionality)
Options
1 x 0.96″ OLED display
Wifi 2.4 & 5Ghz module for testing and design purpose
VolumioPro Module Rev1.0
Digital S/PDIF Coaxial output on TOSLINK connector, up to 192kHz/24bit [external]
SD-card interface for flashing the OS image on the module and for increased storage [internal]
Get information & quote
